Microfluidic

Smart solutions at the microscale

Microfluidic technology is centered on the manipulation of minute fluid volumes, Integrating sample processing, reaction and detection on the chip, Bring about disruptive changes in in vitro diagnosis, drug research and life science studies.

Miniaturization of equipment
Integration
High-flux
Low Consumption of testing
Less pollution

Key technology

Micro-fluidic chip processing(precision injection)

  • It has process technologies such as milling, electroforming, lithography, and masking, and the surface finish of the mold reaches A0 level.
  • The microfluidic processing range is 10-1000μm, and the maximum aspect ratio is 10:1.

Micro-fluidic chip bonding

  • Covering multi-material chip processing capabilities, such as PMMA, COC, COP, PDMS, PC, PS and other material processing.
  • Bonding process: thermosetting, ultrasonic bonding, laser bonding, hot-press bonding, with bonding alignment accuracy of ±5 μm.
  • Multi-layer chip alignment bonding processing accuracy ±20 μm.

Micro-channel surface treatment

  • Surface modification process: Plasma sputtering coating modification, such as wetting behavior, chemical resistance, permeability, conductivity, functionalization modification (introducing modified genes), etc. processes

Microfluidic chip reagent packaging

  • Reagent packaging process: freeze-dried microbeads production, freeze-dried balls packaging, micro-liquid sample spotting, in-situ freeze-drying, reagent liquid encapsulation.

Application area

POCT

Gene sequencing

Cell Sorting

Organs-on-chips

R&D of Drugs

End-to-End Consulting from Design to Mass Production.
